MB-QM67  for    Ultra-slim  System

Specification

MB-QM67 Specifications:

* 2nd Generation Intel® Core™i7 / i5 / Celeron® QC / DC processors
* Two DDR3 DIMM, Max. 8GB memory
* Supports CRT, DVI, LVDS and HDMI
* Dual Gigabit Ethernet
* 8x USB 2.,0, 2x USB 3.0, 4x COM, 4x SATA II, 2x SATA III
* 1x PCI-E(x16), 1x Mini PCI-E(x1)
* WatchDog timer, Digital I/O

CPU
Socket G2 (rPGA988B) 2nd Generationfor Inte® Core™ i7 / i5 / Celeron® QC / DC processors

Chipset
Intel® QM67 Express Chipset

BIOS
AMI BIOS, ACPI supported

System Memory
Two DDR3 DIMM sockets, Max. 8GB
DDR3 800/1066

Integrated VGA
2nd Generation Inte® Core™ i7 / i5 / Celeron® integrated Gfx Gen 5.75 graphics
Supports CRT, DVI-I, DVI-D, LVDS and HDMI
Supports 24-bit dual channel LVDS display

LAN
Inte® 82579LM(MI956AF) / 82579V(MI956F) Gigabit LAN PHY
Inte® 82583V PCI-E Gigabit LAN
2x RJ-45 on board

Audio
Intel® QM67 built-in high definition audio controller with
Realtek ALC892 for 7.1 CH audio

LPC I/O
Fintek F81865-I I/O controller supports 4x COM,

Serial Ports
3x RS-232, 1x RS-232/422/485

Serial ATA
4x SATA II and 2x SATA III

USB
2 USB 3.0 ports on board
8 USB 2.0 ports (4 ports on board, 4 ports via pin header)

Digtial I/O
Supports 4 in, 4out

Watchdog Timer
256 segmaents, 0, 1, 2...255 sec/min

Power Connector
ATX power

Expansion Slot
PPCI-E(x16) & Mini PCI-E(x1) socket

Edge Connectors
CRT, DVI-D, DVI-I, HDMI, Display Port,
2x RJ45, 2x USB 3.0, 4x USB 2.0, 3x1 Audio jacks

Onboard Connectors/Headers
Digital I/O, COM3~COM4, 4x USB, DF13 for LVDS,
2x SATA III , 4x SATA II

EuP Support
Yes

Form Factor
Mini-ITX Motherboard

Dimensions
170mm x 170mm (6.7" x 6.7")

Max. Power Requirement
2nd Generation Intel® Core™ 2.20GHz w/ 2x 4GB DDR3-1333
+3.3V: 1.36A
+5V: 1.9A
+12V: 3.5A
