Mini-ITX Form Factor |
|
|
|
|
|
MODEL |
ITX-6540
|
ITX-3205M
|
ITX-3203M
|
ITX-3220M
|
|
System Chipset |
Intel 815E_B
|
VIA VT8606
|
VIA PLE-133
|
VIA PLE-133
|
|
CPU Supporting |
Intel ULV 400MHz/
650MHz CPU
|
Low Power
Consumption
VIA C3/Eden Series CPU
|
Low Power
Consumption
VIA C3/Eden Series CPU
|
Low Power
Consumption
VIA C3/Eden Series CPU
|
|
LAN Adapter |
Intel 82562ET
|
Realtek 8139D
or Intel 82551QM
|
Realtek 8139C or
Intel 82559ER
|
Realtek 8139C or
Intel 82559ER
|
|
VGA Adapter |
On chip 2D/3D
Graphic Controller
|
VIA 2D/3D
Graphic Controller
|
VIA 2D/3D Graphic
Controller
|
VIA 2D/3D Graphic
Controller
|
|
LCD Supporting |
N/A
|
TFT/DSTN LCD
w/TTL, LVDS
|
TFT LCD
(LVDS via kit optional)
|
N/A
|
|
I/O Port |
4S/1P
|
4S/1P
|
4S/2P
|
4S/2P
|
|
IDE Interface |
2 x IDE 40 Pin UDMA
33/66/100
+ 1 x IDE 44 Pin
(Shared w/IDE 1)
|
2 x IDE 40 Pin UDMA
33/66/100
+ 1 x IDE 44 Pin (Shared w/IDE 1)
|
2 x IDE UDMA
33/66/100
|
2 x IDE UDMA
33/66/100
|
|
DIMM Socket |
1
|
1
|
1
|
1
|
|
Max. RAM Size |
512MB
|
512MB
|
512MB
|
512MB
|
|
VGA Memory |
SMA 1MB
|
SMA 8/16/32MB
|
SMA 2/4/8MB
|
SMA 2/4/8MB
|
|
WDT |
Yes
|
N/A
|
N/A
|
N/A
|
|
Expansion Slot |
PCI + Riser
|
PCI + Riser
|
PCI + Riser
|
PCI + Riser
|
|
USB Feature |
4 USB 1.1 onboard
|
4 USB 1.1 onboard
|
4 USB 2.0 onboard
|
2 USB 1.1 onboard
|
|
Power Supply |
ATX
|
ATX
|
ATX
|
ATX
|
|
Board Size |
170 x 170 mm
|
170 x 170 mm
|
170 x 170 mm
|
170 x 170 mm
|
