SH-6520 (OEM) |
|
|
Specification |
|
| *Heavy-duty steel electroplated for chassis | |
| *Only 1U 5 in 1 KVMA switch, Keyboard, Monitor, Mouse Speaker Drawer. | |
| FLAT
PANEL: *15" TFT LCD Panel Resolution 1024x768(Analog VGA Input ) *12.1/13.3/14.1 TFT LCD Panel (optional) *Built-in 5 languages OSD. *Automatic flat panel shut-off when monitor is in the closed position, or no signal input. |
|
| MOUSE: *Logitech® Touchpad (Microsoft mouse compatible with PS/2 mouse interface) *Logitech® Trackball (optional) |
|
| KEYBOARD: *105 key ALPS® mechanical key switches English Keyboard, compatible to IBM PC/AT, PS/2 keyboard, supports Windows function keys (German, French, Chinese, Japanese....optional) |
|
| Power
Supply: *12V DC input( includes universal 100~240V AC input,12V DC output power supply adapter) *(24V/-48V DC input adapter optional) |
|
| Cable: *Three in one VGA, keyboard (PS/2), Mouse (PS/2) cable set 1.8M 8 set (3M,6M Optional) |
|
| Color
: *Available in black and beige. (Colors available for OEM) |
|
| KVMA
switch: *Up to eight Keyboard/VGA/Mouse/Audio inputs (8 PCs) *Cascade control up to 64 PCs *PS/2 and Serial Mouse Emulation Provided for System Bootup *No software Required-Computer selection Via Pushbuttons, Hot keys, or OSD( On Screen Display) *Quick View scan mode for monitoring selected computers *Hot Pluggable-add or remove computer for maintenance without powering down the switch. *Scan interval 3,8,15,30 sec. |
|
| Optional *UL-2919 rated 3-in-1 cables set with VGA, keyboard (PS/2), Mouse (PS/2),and Audio cable. (1.8M,3M,6M Optional) |
|
| Dimensions | |
| W.482mm x D.508mm x H.44mm | |
| N.W. 9.5 KGS | |
| G.W. 12 KGS | |
| CUFT. 2.72 | |
| Ordering Information: | |
| SH-6520-12-XX-C 12.1" TFT LCD MONITOR | |
| SH-6520-13-XX-C 13.3" TFT LCD MONITOR | |
| SH-6520-14-XX-C 14.1" TFT LCD MONITOR | |
| SH-6520-15-XX-C 15.0" TFT LCD MONITOR | |
| XX=US,GR,FR,CH,JP....(Keyboard languages) | |
| C =B (Black color), W (Beige color) | |
