SH-800/850/900 |
|
|
SH-900 |
|
|
Specification |
|
| *0.05" SECC heavy-duty steel electroplated for chassis. | |
| *Suitable for 6 slots ISA/PCI backplane. | |
| *Cooling fan with filter on front panel. | |
| *The adjustable hold-down clamp over the backplane protects the plug-in card against shock and vibration. | |
|
SH-800 |
|
|
Specification |
|
| *Consists of a special 100W power supply. | |
| *The cooling fan located at rear panel blows out the hot air inside the chassis. | |
| DRIVE SAPCE: For 1 x 3.5"FDD & 1 x 3.5"HDD. | |
|
SH-850 |
|
|
Specification |
|
| *Consists of a PS/2 200W power supply. | |
| *The cooling fan located at rear panel blows out the hot air inside the chassis. | |
| DRIVE SAPCE: For 2 x 3.5"FDD & 2 x 3.5"HDD. | |
| Dimensions | |
| SH-900 | |
| W.330mm x D.410mm x H.116.5mm | |
| N.W. 4.0 KGS | |
| G.W. 5.0 KGS | |
| CUFT. 1.1 | |
| SH-800 | |
| W.65mm x D.392mm x H.163mm | |
| N.W. 3.0 KGS | |
| G.W. 4.0 KGS | |
| CUFT.0.7 | |
| SH-850 | |
| W.114mm x D.392mm x H.163mm | |
| N.W. 3.5 KGS | |
| G.W. 4.5 KGS | |
| CUFT. 1.2 | |
